HN Series: Stationary, Electric Powered, Natural Gas, LP or Diesel Heated

HN Series: Stationary, Electric Powered, Natural Gas, LP or Diesel Heated

Description

Made in the USA for industrial use, the HN Series is a stationary hot water pressure washer that is powered by electricity and heated by your choice of natural gas, propane or diesel. This allows you to install indoors and have hot water on demand in your wash bay at your facility. These models include stainless steel panels, industrial duty motors and pumps and a lifetime heating coil warranty.

Features:

Ready to work when you are:

No need to fill fuel tanks or hunt down a water supply when machine is directly plumbed into natural gas and water lines. The pressure washer can be housed indoors, away from the elements, while installing wash stations remotely outdoors.

Clean and Efficient Heating System:
24v automatic, electronic ignition on low emission natural gas burner. Liquid Propane conversion option or diesel heated option is available on any model.

SpiraLast™ Coil:
The coil is a Hydro Tek manufactured SpiraLast™ heating coil. Robotically fused ½” schedule 80 steel pipe is cold rolled to protect the steel pipe from fatigue and the spiral coil is then surrounded by ceramic insulation and stainless enclosure with double-wall end caps. Ask your dealer about the Lifetime Coil Warranty.

Belt Driven pump:
Low RPM drive – cooler, quieter, continuous duty performance. These industrial triplex pumps feature ceramic plungers for long life. EZ Align™ pump rail system for belt tensioning with a simple adjustment
bolt.

NEMA4 Water Tight Electrical Box:
ETL certified to UL1776 Class 2 for use in wash-down area, exceeds industry standards. Special Hydro Tek control box features easy to use controls and provides instant access to electronics. Standard
diagnostic indicators ensure optimal system performance. Dual voltage switch on most 230v models allows you to simply flip a switch to change to 208v power supply.

Bypass Cool System:
Worry free pump cooling system prevents pump from overheating with system designed pump bypass feature.

Durable Frame Construction:
Welded, powder coated steel, pro-tect-it frame for durability with rustproof stainless coil wrap and front panels. Forklift slots and overhead lifting points to safely reposition machine. Frame integrated hold down tabs.
Stainless steel frame option as well as an option for a removable, stainless back panel available.

Best in Class accessibility:
Easy-remove panels on an open frame design with open backside gives you full access to all components, including EZ Align™ belt tensioning system, electrical box, and burner igniter for efficient preventative maintenance checks.

More Standard Features:

  • Detergent flow metering at full pressure
  • Heavy duty industrial motor with standard thermal overload protection.
  • Adjustable temperature up to 250°F with steam setting
  • Burst disc technology for operator safety
  • Rustproof float tank to regulate incoming water ensuring consistent system performance
  • Heavy duty hose, wand, and trigger gun and quick connect nozzles
  • Remote Ready: Choose an on/off timer remote option or a full function remote option for complete control from the wash site.

Optional Accessories:
Wall mount hose reel, additional wash station remotes, draft diverter, full-feature wall mount remote, 30-min shut off timer, hour meter, downstream soap injection, stainless steel frame, stainless panel wrap kit

Additional information for SCAQMD Permits for customers in Southern California:

http://www.aqmd.gov/

http://www.aqmd.gov/home/permits#Guidelines%20and%20Policies

These links detail the exemptions and certifications that our equipment falls within.

Specifications

ModelPSIGPMTemp.HPVoltage
HN20004E2G20003.9250F5208/230v 1ph 20a
HN25004E2G25003.8250F6.5230v 1ph 29a
HN25004E3G25003.8250F7.5208/230v 3ph 22a
HN25004E4G25003.8250F7.5460v 3ph 11a
HN30004E2G30003.9250F8208/230v 1ph 37a
HN30004E2C30003.9250F8208/230v 1ph 42a
HN35005E3G35004.3250F10208/230v 3ph 29a
HN35005E3C35004.3250F10208/230v 3ph 29a
HN35005E4G35004.3250F10460v 3ph 15a
HN35005E4C35004.3250F10460v 3ph 15a
HN35006E3G35005.5200F15208/230v 3ph
HN35006E4G35005.5200F15460v 3ph



NOTE: Any HN series model can be ordered as a Propane or Diesel heated, stationary pressure washer

Dimensions: 48″l x 21″w x 49″h
Specifications may vary, consult factory for custom models



Request Information

Video

  • Hot Water Pressure Washers

    Hydro Tek hot water pressure washers are designed to tackle the toughest messes wherever they may occur. Our products feature high-quality stainless steel construction, simple controls, and an innovative Spiralast™ heating coil that improves efficiency and reduces your fuel costs. We manufacture the Spiralast™ coils right here in our facility using a proprietary cold rolled process and robotic welds for exceptional strength and unimpeded flow. Our Spiralast™ lifetime warranty is the ONLY lifetime heating coil warranty in the industry.

  • Advantages of a Hot Water Pressure Washer

    Simply by heating up the water, a hot water pressure washer delivers dramatically improved cleaning power compared to a cold water machine. Hot water pressure washers are especially useful for cleaning sticky, greasy, or oily surfaces, because they will loosen the dirt much faster without the large amounts of soap, detergent, or other cleaning chemicals that must be used with a cold water system.

  • Hot Water Pressure Washer Applications

    A hot water pressure washer is essential for any cleanup job involving a sticky, greasy, or oily mess, as well as for applications where a surface must be sanitized. With a variety of models available, including self-contained mobile units with gas, diesel, or electric power, Hydro Tek hot water pressure washers can go anywhere and clean anything. Some common applications include heavy equipment cleaning, vehicle cleaning, graffiti removal, restaurant hood vent cleaning, and livestock facility cleaning.
