What is the Difference between Vertical and Horizontal Coils?

What is the Difference between Vertical and Horizontal Coils?

Most premium pressure washers feature Horizontal style coils while vertical coils can be found on lower cost alternatives. When determining which style to purchase, you should consider some of the environmental factors that can affect the burner and coil performance. When exposed to rain, vertical coils tend to trap small amounts of water at the base of the coil where the burner is located – causing the base plate to rust and potentially causing malfunctions in the burner. Vertical coils typically position the burners closer to the ground than horizontal models leaving the burner open to environmental hazards close to the ground. On a horizontal coil you will find the coil insulation will remain in place while vertical coil insulation can sag over time resulting in a loss of efficiency. Soot is another significant consideration when determining coil orientation. On vertical models, gravity can pull soot into the burner nozzles causing a clog and uneven or poor heating while on horizontal models the soot is dropped away from the burner increasing the reliability of the burner. Hydro Tek utilizes horizontal style coils whenever possible.

Post navigation

  • Hot Water Pressure Washers

    Hydro Tek hot water pressure washers are designed to tackle the toughest messes wherever they may occur. Our products feature high-quality stainless steel construction, simple controls, and an innovative Spiralast™ heating coil that improves efficiency and reduces your fuel costs. We manufacture the Spiralast™ coils right here in our facility using a proprietary cold rolled process and robotic welds for exceptional strength and unimpeded flow. Our Spiralast™ lifetime warranty is the ONLY lifetime heating coil warranty in the industry.

  • Advantages of a Hot Water Pressure Washer

    Simply by heating up the water, a hot water pressure washer delivers dramatically improved cleaning power compared to a cold water machine. Hot water pressure washers are especially useful for cleaning sticky, greasy, or oily surfaces, because they will loosen the dirt much faster without the large amounts of soap, detergent, or other cleaning chemicals that must be used with a cold water system.

  • Hot Water Pressure Washer Applications

    A hot water pressure washer is essential for any cleanup job involving a sticky, greasy, or oily mess, as well as for applications where a surface must be sanitized. With a variety of models available, including self-contained mobile units with gas, diesel, or electric power, Hydro Tek hot water pressure washers can go anywhere and clean anything. Some common applications include heavy equipment cleaning, vehicle cleaning, graffiti removal, restaurant hood vent cleaning, and livestock facility cleaning.
